FOL-DA-TANK® Threaded Flanges – Aluminum
FOL-DA-TANK® Threaded Flanges (aluminum) are lightweight, durable connectors designed for easy installation and secure attachment of hoses to FOL-DA-TANK® portable tanks, ensuring efficient water storage and transfer in various applications.
PRODUCT DESCRIPTION
Flanges are provided on all self-supporting tanks and all Quick-Assemble series tanks. When no longer in use, the SST may be quickly drained through a flange coupling on the side. All self-supporting tanks have reinforced heat sealed patches around the aluminum flange. The flanges are made from high quality al-mag alloy which provides top quality castings and threads. The flanges can also be mounted on the side walls of the FOL-DA-TANK framed tank. This application is used when drafting with a Low-Flow Strainer attached to the side wall.
Flanges range from 1.5″ – 6″ with standard NST male or female threads available.
FEATURES
- CAM and GROOVE
- Inner and outer flange kit available
- Call for others
- Standard NST Threads — Male or Female
SPECIFICATIONS
| Threads | NST, NPSH |
|---|---|
| Couplings | STORZ |
| Connection | CAM, GROOVE |
TECHNICAL DATA
Part No. |
Size in/mm |
|---|---|
FLC-1.5 |
1.5”/40 |
FLC-2.0 |
2”/50 |
FLC-2.5 |
2.5”/60 |
FLC-3.0 |
3”/80 |
FLC-4.0 |
4”/100 |
FLC-4.5 |
5”/110 |
FLC-5.0 |
5”/130 |
FLC-6.0 |
6”/150 |
