May 30, 2021Avon Protection MP-PAPR™ (Powered Air Purifying Respirator)
The Avon Protection MP-PAPR™ (Powered Air Purifying Respirator) provides reliable respiratory protection with a lightweight, comfortable design, offering enhanced filtration and airflow for extended use in hazardous environments.
PRODUCT DESCRIPTION
The Avon MP-PAPR module delivers a compact and easily integrated PAPR unit providing cooling, lower user burden and reduced pulmonary stress. The unique shape and construction allow the wearer to mount the PAPR in multiple ways, maximizing integration while delivering higher protection levels and improved well-being. A complete set of certifications allows the user to add Avon MP-PAPR to existing fielded systems such as the 50 Series APR’s, convert into a combination PAPR (Avon CS-PAPR) or revert back to an Avon EZAir configuration.
Suitable For:
- First Responders
- Military
- Special Forces
FEATURES
- Increased operational time
- Multiple long duration battery packs
- Constant flow rate reduces inhalation resistance
- Hot swap battery for rapid exchange
- Optimized Integration
- Ergonomically back mounted carrier system with integrated hydration option
- Direct MOLLE mount to ballistic vests or other equipment
- S-Shape hose with crush proof technology delivers superior integration
- Intelligent Control Systems
- Automatic flow control preserves battery life
- Low flow and battery alarm alert
- Automatic dual speed function
- Novel Material Technologies
- Unique one size lightweight and flexible hose
- Dual wall construction hose which is crush proof
SPECIFICATIONS
Unit Size |
420mm L (16.5″) x 115mm H (4.5″) x 140mm W (5.5″) |
Unit Weight (No Battery or Filter) |
0.92 kg (2.02 lbs.) |
Unit Weight (No Filter – 6xCR123) |
1.2 kg (2.60 lbs.) |
Flow Rate |
120 LPM controlled flow |
Operational Noise @ 120 LPM |
|
Run Time |
CR123, Li-Ion battery 4+ hours (filter clogged)
Li-Ion Rechargeable battery 8+ hours (filter clogged) |
Operational Temperature |
-20°C to 52°C (-4°F to 123°F) |
Protection Factor PAPR mode |
10,000 (PAPR On), 2,000 (PAPR Off) |
Alarms |
Low Battery (can be silenced), restricted flow, high resistance |
Construction |
CBRN Hardened Butyl and Noryl |
Operation |
Smart integrated power button. Remote power button on hose (optional) |
Interface with APR |
Crush Proof hose with close fit 40mm (STANAG) APR connection, one size fits all |
EMI Shielded |
MIL-HDBK-235 |
Intrinsically Safe |
No |
TECHNICAL DATA
Part Number |
Description |
---|---|
600201 |
Battery Charger |
600214 |
Li-Ion Rechargeable Battery 5200mAh |
600213 |
Replaceable Battery 2800mAh |
600368 |
User Instructions Manual |
75027-107 |
Escape Hood, Nuclear, Biological, and Chemical, Size: Large |
